常见钢丝螺套使用参数表：
|
|
螺纹规格
|
公称长度
|
圈数
|
自由状态外径
|
钻头
|
|
2×0.4
|
1d
1.5d
2d
|
2.9
4.7
6.5
|
2.6 - 2.8
|
2
|
|
2.5×0.45
|
1d
1.5d
2d
|
3.5
5.9
8.1
|
3.3 - 3.5
|
2.6
|
|
3×0.5
|
1d
1.5d
2d
|
4
6.3
8.7
|
3.8 - 4.0
|
3.1
|
|
4×0.7
|
1d
1.5d
2d
|
3.7
6
8.4
|
5.15 - 5.35
|
4.1
|
|
5×0.8
|
1d
1.5d
2d
|
4.3
6.9
9.7
|
6.35 - 6.6
|
5.2
|
|
6×1
|
1d
1.5d
2d
|
45.0
7
9.6
|
7.6 - 7.85
|
6.2
|
|
8×1
|
1d
1.5d
2d
|
6.1
9.5
13
|
9.85 - 10.1
|
8.2
|
|
8×1.25
|
1d
1.5d
2d
|
4.7
7.4
10.6
|
9.85 - 10.1
|
8.3
|
|
10×1
|
1d
1.5d
2d
|
7.6
12
16.3
|
12.1 - 12.5
|
10.2
|
|
10×1.5
|
1d
1.5d
2d
|
5
8
11.2
|
12.1 - 12.5
|
10.3
|
|
12×1.5
|
1d
1.5d
2d
|
6.2
9.8
13.5
|
14.4 - 14.8
|
12.4
|
|
12×1.75
|
1d
1.5d
2d
|
5.2
8.4
11.7
|
14.4 - 14.8
|
12.4
|
|
16×1.5
|
1d
1.5d
2d
|
8.3
13
17.7
|
19.4 - 19.9
|
16.4
|
|
16×2
|
1d
1.5d
2d
|
6.0
9.7
13.3
|
19.4 - 19.9
|
16.5
|
|
20×2.5
|
1d
1.5d
2d
|
6.3
10
13.7
|
23.7 - 24.2
|
20.5
|
|
24×3
|
1d
1.5d
2d
|
6.3
10
14
|
28.6 - 29.1
|
24.6
|
|
|
|
|
自由状态圈数与装配长度对应表：
|
|
|
4
|
6
|
8
|
10
|
12
|
14
|
16
|
18
|
20
|
|
2×0.4
|
2.19
|
3.09
|
3.98
|
4.88
|
5.78
|
6.67
|
7.57
|
|
|
|
2.5×0.45
|
2.48
|
3.50
|
4.51
|
5.53
|
6.54
|
7.56
|
8.57
|
|
|
|
3×0.5
|
2.73
|
3.85
|
4.97
|
6.08
|
7.20
|
8.32
|
9.43
|
|
|
|
4×0.7
|
3.77
|
5.31
|
6.85
|
8.38
|
9.92
|
11.46
|
12.99
|
|
|
|
5×0.8
|
4.32
|
6.08
|
7.84
|
9.60
|
11.36
|
13.12
|
14.88
|
|
|
|
6×1
|
5.36
|
7.54
|
9.72
|
11.90
|
14.08
|
16.26
|
18.44
|
|
|
|
7×1
|
5.37
|
7.55
|
9.73
|
11.91
|
14.10
|
16.28
|
18.46
|
20.65
|
22.82
|
|
8×1
|
5.37
|
7.56
|
9.74
|
11.93
|
14.11
|
16.30
|
18.48
|
20.67
|
22.85
|
|
8×1.25
|
6.70
|
9.43
|
12.15
|
14.88
|
17.60
|
20.33
|
23.05
|
25.78
|
28.50
|
|
10×1
|
5.42
|
7.64
|
9.85
|
12.06
|
14.27
|
16.48
|
18.70
|
20.91
|
23.12
|
|
10×1.25
|
6.81
|
9.44
|
12.16
|
14.89
|
17.61
|
20.34
|
23.06
|
25.79
|
28.51
|
|
10×1.5
|
8.01
|
11.26
|
14.52
|
17.78
|
21.03
|
24.29
|
27.54
|
30.80
|
34.05
|
|
12×1.5
|
8.00
|
11.26
|
14.51
|
17.76
|
21.02
|
24.27
|
27.52
|
30.77
|
34.02
|
|
12×1.25
|
6.73
|
9.46
|
12.18
|
14.91
|
17.63
|
20.36
|
23.08
|
25.81
|
28.53
|
|
12×1.75
|
9.12
|
12.68
|
16.60
|
20.30
|
23.98
|
27.50
|
31.15
|
34.75
|
38.50
|
|
14×1.25
|
6.75
|
9.48
|
12.20
|
14.93
|
17.65
|
20.38
|
23.11
|
25.83
|
28.55
|
|
14×1.5
|
8.04
|
11.30
|
14.57
|
17.84
|
21.11
|
24.38
|
27.64
|
30.91
|
34.18
|
|
16×1.5
|
8.09
|
11.38
|
14.08
|
17.97
|
21.27
|
24.56
|
27.86
|
31.15
|
34.44
|
|
16×2
|
10.10
|
14.30
|
18.50
|
22.80
|
27.10
|
31.30
|
35.60
|
39.60
|
43.70
|
|
18×1.5
|
|
11.44
|
14.75
|
18.06
|
21.37
|
24.68
|
27.99
|
31.30
|
34.62
|
|
20×1.5
|
|
11.50
|
14.83
|
17.16
|
21.49
|
24.82
|
28.15
|
31.48
|
34.82
|
|
20×2.5
|
|
17.40
|
22.48
|
27.50
|
32.60
|
37.70
|
42.80
|
47.80
|
53.00
|
|
22×1.5
|
|
11.55
|
14.90
|
18.25
|
21.60
|
24.95
|
28.30
|
31.65
|
35.01
|
|
24×1.5
|
|
|
14.98
|
18.36
|
21.73
|
25.10
|
28.47
|
31.84
|
35.21
|
|
24×3
|
|
20.70
|
26.80
|
32.80
|
38.80
|
44.90
|
51.00
|
57.00
|
63.10
|
|
|
|
|
